Mobilize Your Containers

Name: Bison
Price range: $

For total independence, the C-Lift T Series equips you to rapidly deploy valuable containerized assets, without the costs, delays, and downtime that come from relying on third-party vendors.

With lift capacities of up to 30 tonne or 66,000 lbs, the T Series is an ideal solution for defense applications, field services, emergency response, event logistics, and containerized energy.

Putting You in Control

Mobilize Containers

Make Containers Self Sufficient

Eliminate Crane Hire

Avoid Delays And Downtime

Lower Transport Costs

C-Lift T Series

Legs Travel With The Container

The legs stow safely at the front and rear of the container during transport, staying inside regular vehicle width limits.
Quick and Easy to Deploy

To deploy, the legs are simply swung into position and locked in place with a two-bolt brace. The lift is controlled by a wireless handheld remote.
Self levelling control system

Onboard sensors control the pumps and motors, keeping the container level and each leg synchronized. The default mode is self-leveling, however, the operator can select and control individual legs, or groups of legs, if required.
Works on uneven ground

An articulating footplate gives the T Series a stable base for lifting containers on rough, loose, and uneven surfaces.
Lift capacity up to 30 tonne | 66,000 lbs

The T Series is available in two lift capacities. The C-Lift T20 with 20 tonne | 44,000 lbs working load limit. And the C-Lift T30 with a 30 tonne | 66,000 lbs working load limit.
Legs Bolt To Corner Castings

The four telescopic lifting legs bolt securely to the ISO corner castings, without modifying the container structure. The legs can be detached and transferred quickly and easily between containers.

C-Lift T Series

Legs Travel With The Container
Quick and Easy to Deploy
Self levelling control system
Works on uneven ground
Lift capacity up to 30 tonne | 66,000 lbs
Legs Bolt To Corner Castings

The legs stow safely at the front and rear of the container during transport, staying inside regular vehicle width limits.

To deploy, the legs are simply swung into position and locked in place with a two-bolt brace. The lift is controlled by a wireless handheld remote.

Bison Container Lifting Legs with container in the air

Onboard sensors control the pumps and motors, keeping the container level and each leg synchronized. The default mode is self-leveling, however, the operator can select and control individual legs, or groups of legs, if required.

An articulating footplate gives the T Series a stable base for lifting containers on rough, loose, and uneven surfaces.

The T Series is available in two lift capacities. The C-Lift T20 with 20 tonne | 44,000 lbs working load limit. And the C-Lift T30 with a 30 tonne | 66,000 lbs working load limit.

The four telescopic lifting legs bolt securely to the ISO corner castings, without modifying the container structure. The legs can be detached and transferred quickly and easily between containers.

C-Lift T Series

Hydraulic Counterbalance Valves

Hydraulic counterbalance valves ensure the container will stay elevated in the event of an unexpected power outage or hydraulic failure.
Wireless Remote

A wireless handheld remote control allows the operator to move freely, monitor each lift, and remain a safe distance from the elevated container.
Emergency Stops

An emergency stop button on the remote will stop the T Series on demand. A second hardwired emergency stop button can be positioned on the ground, a safe distance from the elevated container.
Safety rated control system

A safety rated control system, with dual channel redundancy, controls the pumps and motors, keeping the container level and each leg synchronized.
Quality Construction

The T Series legs are constructed from high-strength structural steel and are physically proof tested to 150% times their working load limit before shipping.

Hydraulic counterbalance valves ensure the container will stay elevated in the event of an unexpected power outage or hydraulic failure.

3026 865x487 T30 Containre Lifting Bison Remote

A wireless handheld remote control allows the operator to move freely, monitor each lift, and remain a safe distance from the elevated container.

3027 865x487 T30 Containre Lifting Bison Emergency Stop

An emergency stop button on the remote will stop the T Series on demand. A second hardwired emergency stop button can be positioned on the ground, a safe distance from the elevated container.

A safety rated control system, with dual channel redundancy, controls the pumps and motors, keeping the container level and each leg synchronized.

The T Series legs are constructed from high-strength structural steel and are physically proof tested to 150% times their working load limit before shipping.

Us
Metric

Models	C-Lift T20	C-Lift T30	C-Lift T20	C-Lift T30
Lift Capacity	44,000 lbs	66,000 lbs	20,000 kg	30,000 kg
Lift Height	65 in		165 cm
Reversing Clearance	20 in		50 cm
Leg Weight	480 lb	572 lbs	220 kg	260 kg
Operating Temperature	14°F to 104°F		-10°C to +40°C
IP Rating	Portable HPU IP54. Mounted HPU IP56.		Portable HPU IP54. Mounted HPU IP56.
Standard Power Supply	External electric supply, from portable generator or mains. 207 - 240 VAC, 50 - 60 Hz, 10 - 15 Amps		External electric supply, from portable generator or mains. 207 - 240 VAC, 50 - 60 Hz, 10 - 15 Amps
Alternative Power Supply	Built in 24V DC rechargeable battery pack. Only available with T20 Mounted HPU. Charge with 110V - 240V, 50 - 60 Hz, 10 - 15 Amps.		Built in 24V DC rechargeable battery pack. Only available with T20 Mounted HPU. Charge with 110V - 240V, 50 - 60 Hz, 10 - 15 Amps.
Construction	High strength structural steel. Each leg is factory proof tested to 150% x rated load. Off the shelf hydraulics, for easy servicing. Zinc-plated exterior, for long life cycle.		High strength structural steel. Each leg is factory proof tested to 150% x rated load. Off the shelf hydraulics, for easy servicing. Zinc-plated exterior, for long life cycle.
Design Standard	CE compliant and designed in accordance with BS EN 1494:2000+A1:2008, the British Standard for mobile or moveable jacks.		CE compliant and designed in accordance with BS EN 1494:2000+A1:2008, the British Standard for mobile or moveable jacks.

Trusted to perform

Bison combines first-class engineering, industrial strength components and rigorous manufacturing, to deliver quality equipment you can trust to perform in the toughest conditions.

Putting you in control

With Bison, you'll get more self-sufficiency and control over your operations, and the freedom to lift, weigh and move containers without relying on contract cranes, truck scales and heavy handling equipment.

From solutions to support

Working with Bison means exceptional service at every touch point, from our multi-lingual sales team, to our comprehensive training and global support network.

Case Study

Elevating Mobile Education with C-Lift T Series

"Definitely worth the investment, especially on a long container where you’re moving around a lot and don’t want to continually have to do a lot of logistics with cranes or tilt trucks.” - Mark Olsen, Senior Project Manager, Health Science X

Read the full story
